? application:
f transfer injection of low sulphur fluid, sour fluid, fluid included with aromatic content; gas transfer; flow line.
? stard: api spec 17k/ iso 13628-10
? api monogram no.: 17k-0008
? hose structure:
inner carcass: stainless steel carcass
internal tube: particular polymer engineering plastic as inner sealing tube
internal rubber liner: hnbr based inner sealing elastomer, which is good f fluid with h2s, oil resistance, crosion resistance, high temperature resistance, gas permeation resistance
breaker layer external protection layer: high tension textile fabric
reinfcement f maj pressure withst: high strength steel cable
fire shield layer: glass fiber cloth
cover: neoprene rubber based cover layers, fire resistance, wear resistance, oil resistance, ozone & ageing resistance, uv resistance which is applicable f critical marine environment
? fire resistance meet api spec 16c, at 704℃ ×30min
? external protection layer of hose can be equipped with stainless steel arm, stainless steel wire polyethylene spiral sleeve, etc. accding to customer requirement
? wking temperature range: class ⅱ , -25 to +100 ℃
? max. aromatic content 30%
? max. content of h?s, up to 3000ppm while temperature at 60℃ , max.1000ppm while temperature at 100℃
? maximum length: 70m
? length tolerance: length up to 6.4m, with tolerance ± 64 mm; length longer than 6.4m with tolerance ± 1％
? measurement basis of minimum bending radius (mbr) is center line of each hose
